Model: XNiteNikonSB900-715  Nikon Electronic SB-900 Electronic Flash Converted to Infrared (IR) 715nm



The specifications listed below are for the stock flash - not the infrared flash.  Please understand that the flash performance with your camera will vary with a variety of factors. Please read more at IR Camera Flashes



bullet
Guide Number
34/111.5 (ISO 100, m/ft), 48/157.5 (ISO 200, m/ft)

bullet
Electronic Construction
Automatic Insulated Gate Bipolar Transistor (IGBT) and series circuitry

bullet
Flash Exposure Control
Camera’s sync modes: Slow-sync; Red-eye reduction in Slow-sync; Front-curtain sync; Rear-curtain sync; Rear-curtain Slow-sync Shooting functions: Auto FP High-Speed sync; FV Lock flash

bullet
Lens Coverage
bullet17 to 200mm (FX-format, Automatic mode)
bullet12 to 200mm (DX-format, Automatic mode)
bullet12 to 17mm (FX-format, Automatic mode with built-in wide-angle panel deployed)
bullet8 to 11mm (DX-format, Automatic mode with built-in wide-angle panel deployed)


bullet
Minimum Recycling Time
bullet4.0 sec. with Alkaline-manganese (1.5V)
bullet4.5 sec. with Lithium (1.5V)
bullet3.0 sec. with OxyrideTM (1.5V)
bullet2.3 sec. with Ni-MH (2600 mAh)


bullet
Flash Duration
bullet1/880 sec. at M1/1 (full) output
bullet1/1100 sec. at M1/2 output
bullet1/2550 sec. at M1/4 output
bullet1/5000 sec. at M1/8 output
bullet1/10,000 sec. at M1/16 output
bullet1/20,000 sec. at M1/32 output
bullet1/35,700 sec. at M1/64 output
bullet1/38,500 sec. at M1/128 output

bullet
Required Power Source
Use four AA-type batteries of any of the following types:
bulletAlkaline-manganese (1.5V) batteries
bulletLithium (1.5V) batteries
bulletNi-MH (1.2V) batteries

bullet
Dimensions
Approx. 3.0 × 5.7 × 4.7 in. (78.0 × 146.0 × 118.5 mm)

bullet
Weight
Approx. 14.6 oz. (415g)

bullet
ISO Range
100 to 6400 ISO

bullet
Optional Power Supply
bulletSD-9 High-Performance Battery Pack
bulletSD-8A High-Performance Battery Pack
bulletSK-6 Power Bracket Unit




bullet
Minimum Number of Flashes
110 with Alkaline-manganese (1.5V)
230 with Lithium (1.5V)
190 with Ni-MH (2600 mAh)
Note: When firing Speedlight at full output once every 30 seconds (120 seconds with lithium).

bullet
Wireless Flash Modes
bulletOff
bulletMaster
bulletMaster (Repeating)
bulletRemote
bulletSU-4

bullet
Wireless Communication Channels
Four
Channels

bullet
Wireless Groups
Three

bullet
Supplied Accessories
bulletAS-21 Speedlight Stand
bulletSW-13H Diffusion Dome
bulletSJ-900 Color Filter Set
bulletSZ-2 Color Filter Holder
bulletSS-900 Soft Case
*Supplied accessories may differ depending on country or area.
