Nikon D7100: 24.1 MegaPixel Prosumer Infrared-Enabled Camera

XNiteNikonD7100         UV+Visible+IR

XNiteNikonD7100IR     High-Red (590nm or 665nm),  IR-Only (715nm or 830nm)









(Lens not included)

The Nikon D7100 is a prosumer digital SLR camera. This camera offers great IR sensitivity, dynamic range and low noise.

We can modify this camera to be IR+Visible+UV, High-Red and IR-Only.

bulletIR+Visible+UV: Camera seee everything the sensor is cable of seeing.  Camera will see some UV, the entire visible range and infrared from 715nm to 1200nm.
bulletHigh-Red

665nm: Camera will see from 665nm to 1200nm.  Red channel will see visible red and infrared.  Blue and green channels will only see infrared.

590nm: Camera will see from 590nm to 1200nm.  Red channel will see visible red and infrared.  Green channel will see come visible green and infrared.  Blue channel will only see infrared.

bulletIR-Only

715nm:  All channels  only see infrared.  The red channel is the most open to the IR and contains somewhat different information than the blue and green channels allowing for some creative color effects such as red-blue channel swapping to get deep blue skies.  A 715nm converted camera sees about the same amount of light as a stock camera so apertures and shutter are similar to a stock camera.  715nm is similar to a Hoya RM72 or Wratten 89B.

830nm:  All channels only see infrared.  Camera loses about 2 stops of exposure.  Once you equalize color levels, picture will be almost completely black and white.  The infrared effect is more intense at 830nm - skies are darker, clouds whiter and you see further through smoke and haze.

We can modify your D7100 for $450 + return S&H ($20 UPS ground insured domestic USA).  Turn around is 1 or 2 days from receipt.  We only need the camera and charged battery for testing along with a cover letter specifying the conversion type.

Specifications

bullet
Lens Mount
Nikon F bayonet mount

bullet
Picture Angle
Effective picture angle 1.5x (Approx.) conversion factor (Nikon DX format)

bullet
Effective Pixels
24.1 million

bullet
Sensor Size
23.6 x 15.6mm

bullet
Image Sensor Format
DX

bullet
Image Sensor Type
CMOS

bullet
Total Pixels
24.1 million

bullet
Dust-Off Reference Photo
Yes

bullet
Image Area (pixels)
DX-format
(L) 4928 x 3264
(M) 3696 x 2448
(S) 2464 x 1632

bullet
File Format
NEF (RAW): lossless compressed or compressed 12 or 14 bit
JPEG: JPEG-baseline-compliant; can be selected from Size Priority and Optimal Quality
MOV

bullet
Picture Control
Landscape
Monochrome
Neutral
Nine User-customizable Settings
Portrait
Standard
Vivid

bullet
Storage Media
SD
SDHC
SDXC

bullet
Card Slot
2 Secure Digital (SD)

bullet
File System
Compliant with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras

bullet
Viewfinder
Eye-level pentaprism single-lens reflex viewfinder

bullet
Viewfinder Frame Coverage
100%Approx.

bullet
Viewfinder Magnification
0.95x Approx.

bullet
Viewfinder Eyepoint
19.5mm

bullet
Viewfinder Diopter Adjustment
-3 to +1m⁻?

bullet
Focusing Screen
Type B BriteView Clear Matte Mark II with AF area brackets (grid lines can be displayed)

bullet
Reflex Mirror
Quick-return type

bullet
Depth-of-field Control
Yes

bullet
Lens Compatibility at a Glance***
AF-S or AF lenses fully compatible
Metering with AI lenses

bullet
Compatible Lenses
AF-NIKKOR for F3AF not supported
AI-P NIKKOR: All functions supported except 3D color matrix metering II
DX AF NIKKOR: All functions possible
Electronic rangefinder can be used if maximum aperture is f/5.6 or faster
IX Nikkor lenses cannot be used
Non-CPU: Can be used in modes A and M; color matrix metering and aperture value display supported if user provides lens data (AI lenses only)
Other AF NIKKOR: All functions supported except 3D color matrix metering II
PC Micro-NIKKOR does not support some functions
Type G or D AF NIKKOR: All functions supported

Please note that the anti-dust system is normally disabled on our conversions.  Live View will work correctly.

Modification will void your warranty.
