Smartphone Camera and the Eye

We are often asked if we can make a special ink that a normal cell phone camera can see but the human eye can't.  And they usually add that the camera can't have any special filters and no special sort of lighting.  With those restrictions, the answer, in short, is no.

One typical scenario is they want to make a poster or picture where the camera can see something the eye can't.

The camera phone has a silicon sensor that can see more wavelengths, in the ultraviolet (UV) and infrared (IR), but all stock color cameras also have an IR Cut Filter (ICF) that blocks those UV and IR frequencies.  The reason manufacturers put in an ICF is that most people want the camera picture to look like what they  are seeing with their eyes.  You wouldn't be very happy if you took a picture of your mom outside in sunlight, but the resulting picture colors were horribly wrong.

Here is an example.  First a camera picture with the ICF.

Next, here is a picture with no ICF where the camera sees UV, Visible and IR light at the same time.

So you can see that an ICF is necessary for a normal camera sensor to take a color correct picture.  Some objects might look correct but many will not because different objects have different IR and UV absorption and reflectivity.  The resulting picture is also related to the illumination spectra so an outdoor sunlight picture where there is UV, Visible and IR light will look different than inside in a room with no windows and lit with fluorescent lights where there is almost only visible light.  In a fluorescent lit room, a camera with no ICF will take mostly color correct pictures.  Fluorescent lights emit almost only visible light while incandescent (hot bulbs with filaments) emit visible and infrared.  BTW, that is also why fluorescent light bulbs are more energy efficient than incandescent bulbs.

Another response I get is that, "I read on the internet that if you point a remote control at the camera and the phone can see a light flash from the remote, that the phone can see infrared since the remote is sending an infrared signal."  Close, but not quite.  Yes, most remote controls use an IR Light Emitting Diode (LED) to send the remote control codes.  However, the IR LED is pulsing at a high power level.  Some of the IR leaks past the ICF and the camera sees it.

No filter is perfect and some unwanted light gets through.  But the ICF is pretty good at blocking IR and very good at passing visible light so even if you did have a special ink that you can see in the IR but not in the visible (we make some of these inks), you won't see it in outdoor sunlight because the visible light is being passed at near 99% while the IR is blocked to about 1%.

One way you could make an invisible message show up to a user with a stock camera phone would be to have an IR long pass filter (we make these) with IR LED's behind the IR filter.  The IR filter looks like black glass to the human eye, but is almost completely clear to the IR light (opposite of the ICF).  If the IR LED is bright enough, it will leak past the camera's ICF, but the human eye will only see the black filter glass.

There are some other ways you could do this as well, but they involve having special filters on the camera, or modifying the camera and special lighting.
