| Sensor Type: |
CMOS |
| Sensor Manufacturer: |
Canon |
| Effective Megapixels: |
18.0 |
| Sensor Format: |
APS-C |
| Sensor size: |
332.27mm2 (22.30mm x 14.90mm) |
| Approximate Pixel Pitch: |
4.30 microns |
| Focal Length Multiplier: |
1.6x |
| Aspect Ratio: |
3:2 |
| Color Filter Type: |
RGBG |
| Anti Aliasing Filter: |
Fixed |
| Self-Cleaning: |
Yes |
| Sensor shift image stabilization: |
No |
| On-Sensor Phase Detect: |
No |
| DxO Sensor Score: |
66 |
| DxO Color Depth Score (bits): |
22.2 |
| DxO Dynamic Range Score (evs): |
11.5 |
| DxO Maximum Effective ISO Score (iso): |
813 |
| Image Resolution: |
5184 x 3456 (17.9 MP, 3:2),
3888 x 2592 (10.1 MP, 3:2),
3456 x 2304 (8.0 MP, 3:2),
2592 x 1728 (4.5 MP, 3:2),
1920 x 1280 (2.5 MP, 3:2),
720 x 480 (0.3 MP, 3:2) |
| Image File Format: |
JPEG (EXIF 2.3), 14-bit RAW, MRAW, SRAW |
| Continuous-mode frames/second: |
5.3 |
| Can take movies: |
Yes |
| Movie Resolution: |
1920x1080 (30/25/24)
1280x720 (60/50)
640x480 (60/50) |
| Movie File Format: |
.MOV (H.264) |
| Composite Video Out: |
Yes |
| NTSC/PAL Switchable Video: |
Yes |
| Video Usable as Viewfinder: |
Yes |
| HD Video Out: |
Yes |
| HD Video Connection: |
HDMI |
| Lens Mount: |
Canon EF/EF-S |
| Lens: |
Canon EF-S 18-135mm f/3.5-5.6 IS |
| Focal Length (35mm equivalent): |
29 - 216mm |
| Focal Length (actual): |
18 - 135mm |
| Zoom Ratio: |
7.50x |
| Aperture Range: |
f/3.5 - f/22 (wide) / f/5.6 - f/38 (tele) |
| Normal Focus Range: |
45 cm to Infinity
17.7 in to Infinity |
| Macro Focus Range: |
|
| Filter Thread: |
67.0mm |
| Thread Type: |
n/a |
| Optical Image Stabilization: |
Yes |
| Digital Zoom: |
|
| Digital Zoom Values: |
|
| Auto Focus: |
Yes |
| Auto Focus Type: |
AF-dedicated CMOS Sensor, 9-points, all cross-type AF points, center dual cross-type point for f/2.8 |
| Auto Focus Assist Light? |
Yes |
| Manual Focus: |
Yes |
| Viewfinder: |
Optical / LCD |
| Viewfinder Type: |
SLR type; eye-level pentaprism, 96% coverage, 0.95x magnification, 22mm eyepoint, -3 to +1 diopter |
| Focus Peaking: |
No |
| EVF Resolution: |
n/a |
| Viewfinder Magnification (35mm equivalent): |
0.59x |
| Viewfinder Magnification (nominal/claimed): |
0.95x |
| Eye-level Viewfinder: |
Yes |
| Rear Display: |
Yes |
| Rear Display Size (inches): |
3.0 |
| Rear Display Resolution: |
1,040,000 dots |
| Touchscreen: |
No |
| Articulating Screen: |
Yes |
| Tilt Swivel Screen: |
Yes |
| Selfie Screen: |
Yes |
| Max Playback Zoom: |
10.0x |
| Top Deck Display: |
Yes |
| Maximum ISO (native): |
6400 |
| Minimum ISO (native): |
100 |
| ISO Settings: |
Auto, 100 - 6400 in 1/3 or 1EV steps, H=12800 |
| Auto ISO Mode: |
Yes |
| White Balance Settings: |
Auto, Daylight, Shade, Cloudy, Tungsten, White Fluorescent, Flash, Custom, Kelvin 2,500K - 10,000K |
| Shutter Speed Range: |
30 - 1/8000 |
| Bulb Mode: |
Yes |
| Exposure Compensation: |
+/- 5.0EV in 0.3EV steps |
| Metering Modes: |
63-zone (dual layer) Evaluative, Center-weighted, Partial (6.5%), Spot (2.8%) |
| Program Auto Exposure: |
Yes |
| Aperture Priority: |
Yes |
| Shutter Priority: |
Yes |
| Full Manual Exposure: |
Yes |
| Creative Exposure Modes: |
Creative Auto, Portrait, Landscape, Macro, Sports, Night Portrait, No Flash, Custom User Setting |
| Self Timer: |
10 or 2 seconds |
| Time Lapse (intervalometer): |
|
| High Resolution Composite: |
No |
| Built-in Flash: |
Yes |
| Flash Modes: |
E-TTL II |
| Flash Guide Number (ISO 100): |
13.0 m / 42.7 ft. |
| Flash Range Description: |
Lens aperture dependent |
| Max Flash Sync: |
1/250 |
| Flash Exposure Compensation: |
+/- 3.0 EV in 0.3EV steps |
| External Flash Connection: |
Hot Shoe |
| Built-In Wireless Flash Control: |
Full TTL exposure |
| Usable Memory Types: |
SD / SDHC / SDXC |
| UHS Support: |
No UHS support |
| Other Memory: |
|
| Dual Card Slots: |
No |
| RAW Capture Support: |
Yes |
| Uncompressed Format: |
14-bit RAW, MRAW, SRAW |
| Movie File Format: |
.MOV (H.264) |
| Included Memory: |
No memory included |
| Included Memory Type: |
|
| Built-In Wi-Fi: |
No |
| NFC: |
No |
| Bluetooth: |
No |
| Built-In GPS: |
No |
| Microphone Jack: |
Yes |
| Headphone Jack: |
No |
| External Connections: |
USB 2.0 High Speed |
| PictBridge Compliant: |
Yes |
| DPOF Compliant: |
Yes |
| Remote Control: |
Yes |
| Remote Control Type: |
Optional Wired or Wireless |
| Connections (extended): |
HDMI mini out, external 3.5mm microphone jack |
| Cycle time for JPEG shooting in single shot mode (seconds per frame, max resolution): |
<0.3 |
| Cycle time for RAW shooting in single shot mode (seconds per frame): |
<0.3 |
| Buffer size for RAW shooting in single shot mode (frames): |
14 |
| Cycle time for RAW+JPEG shooting in single shot mode (seconds per shot): |
<0.3 |
| Camera penalizes early shutter press? |
No |
| JPEG shooting speed in burst mode (fps, max resolution): |
5.3 |
| Buffer size for JPEG shooting in burst mode (frames, max resolution): |
34 |
| RAW shooting speed in burst mode (fps): |
5.3 |
| Buffer size for RAW shooting in burst mode (frames): |
15 |
| RAW+JPEG shooting speed in burst mode (fps): |
5.4 |
| Buffer Size for RAW+JPEG shooting in burst mode (frames): |
7 |
| Shutter lag (full AF, wide/mid): |
0.25 seconds |
| Shutter lag (full AF, tele): |
|
| Shutter lag (full AF, live view - DSLR): |
1.10 seconds |
| Shutter lag (prefocused, live view - DSLR): |
0.122 seconds |
| Shutter Lag (manual focus): |
0.083 seconds |
| Shutter lag (full AF, with flash): |
0.29 seconds |
| Shutter Lag (prefocused): |
0.063 seconds |
| Shutter Lag (notes): |
OVF: Full Autofocus Lag, Auto Selection AF = 0.159s Live View: Full Autofocus Lag, Quick Mode (Phase Detect) = 0.999s Full Autofocus Lag, Live Mode (Contrast Detect) = 1.100s Prefocused = 0.122s |
| Startup Time: |
0.4 seconds |
| Play -> Record Time: |
0.3 seconds |
| Flash cycle time, full power: |
2.6 seconds |
| Battery Life, Stills (CIPA Rating Monitor/Live View): |
320 shots |
| Battery Life, Still (CIPA Rating OVF/EVF): |
1100 shots |
| Battery Life, Video: |
|
| Battery Form Factor: |
Proprietary |
| Usable Battery Types: |
LP-E6 Lithium-ion rechargeble |
| Batteries Included: |
1 x Proprietary LP-E6 Lithium-ion rechargeable |
| Battery Charger Included (dedicated charger or AC/USB adapter): |
Yes |
| Dedicated Battery Charger Included: |
Yes |
| Internal Charging Supported: |
No |
| Included Software: |
Canon Solutions Disc (EOS Utility, ZoomBrowser EX/ImageBrowser, Digital Photo Professional.Picture Style Editor, Movie Edit Task, PhotoStitch, Memory Card utility,) |
| OS Compatibility: |
Windows XP SP2/SP3 / Vista, Mac OS X 10.4-10.5 |
| Notes & Features: |
Full HD movies, vari-angle LCD, 5.3 fps burst mode |
