CIR Series

Model: CIR850-25

Professional Color IR Long Range Camera 150 Meters



bullet 1/3" Sony CCD camera
bullet 133 PCs high power IR LEDs
bullet IP66 aluminum professional housing
bullet High efficiency heat evaporating housing
bullet No IR diffuse reflection is glass design
bullet Special design IR LED and circuit prolongs life span of IR LED
bullet IR cut filter automatic switching for normal colors in daylight
bullet 16mm IR lens
bullet IR effective distance:130M(Outdoor)
bullet Dual power optional - 12 VDC or 24 VAC

Specifications:



Illumination



Peak Wave Length

850nm

Projecting Angle

25°

Projecting Distance

150 Meters

On/off Control

CDS/10Lux

Power Supply

AC24V / DC12V

Power Consumption

0.7A(AC24V) / 1.3A(DC12V)



Camera System



Type

Color/Monochrome (IRCut)

Signal Type

NTSC

Pick Up Device

1/3” Color Sony High Resolution

Resolution

480 TV Line

Min Illumination

0 Lux with IR LED

Scanning System

2:1 Interlace

S/N Ratio

> 50 dB

Electronic Shutter

1/100,000 Sec

Lens

16mm IR Lens

White Balance

Auto Tracking

Back Light Compensation

On

Auto Gain Control

On

Gamme

0.45

Video Out

1Vp-p, 75 Ohm

Weight

2800g

Operating Temperature

-10 to +45 DegC



We also have this housing available without the color IR camera here.
