Bandpass IR Filters

Infrared Color Band Pass Series Filters

To go to the 58mm Diameter Infrared Band Pass Section of our online store, please click here.

To go to the 72mm Diameter Infrared Band Pass Section of our online store, please click here.

The Infrared Color Band Pass Series filters are only available in 58mm and 72mm currently.  If you would like another size, please contact us.









This is a series of pictures taken with our IR enabled Sony DSC-F828.  The camera can see from 350nm to 1200nm while the human eye sees from about 400nm (violet) to 725nm (red).

We created a series of infrared band pass filters to pass infrared light while blocking visible light.  The bands are roughly spaced about the same distance as Red Green and Blue in the visible spectrum.  By taking a series of pictures with these different filters and then assigning the different infrared band pass filters into RGB color channels within Photoshop, we have created a down-sampled, or false color, infrared image.  Basically, the combined channels gives you an image of what infrared light would look like if you could see it within our human color space.

To go to the 58mm Diameter Infrared Band Pass Section of our online store, please click here.

To go to the 72mm Diameter Infrared Band Pass Section of our online store, please click here.

The BP Color Series is only currently available in 58mm and 72mm diameter.  If you have a need for another size, please let us know.

  5% Low Cut 50% Low Cut 50% High Cut 5% High Cut
XNiteBPB 650nm 662nm 753nm 787nm
XNiteBPG 735nm 795nm 860nm 935nm
XNiteBPR 888nm 921nm 958nm 1000nm



Visible Spectrum.

Equipment: Sony DSC-F828 IR enabled and XNiteCC1 infrared blocking filter.
Camera is seeing 400nm to 725nm





Visible and Infrared spectrum.

Equipment: Sony DSC-F828 IR enabled with no filter.
Camera is seeing 350nm to 1200nm





Infrared False Color Picture.

Equipment: Sony DSC-F828 IR enabled
XNiteBPR, XNiteBPG and XNite BPB Filters
3 pictures were taken; one with each filter
The three infrared pictures were then brought into Adobe Photoshop and assigned to a color channel.
XNiteBPB assigned to Red
XNiteBPG assigned to Green
XNiteBPR assigned to Blue





Infrared False Color Picture.

Equipment: Sony DSC-F828 IR enabled
XNiteBPR, XNiteBPG and XNite BPB Filters
3 pictures were taken; one with each filter
The three infrared pictures were then brought into Adobe Photoshop and assigned to a color channel.
XNiteBPB assigned to Blue
XNiteBPG assigned to Green
XNiteBPR assigned to Red





Infrared BPB Filter.

Equipment: Sony DSC-F828 IR enabled and XNiteBPB infrared bandpass filter.
Camera is seeing 650nm to 750nm





Infrared BPG Filter.

Equipment: Sony DSC-F828 IR enabled and XNiteBPG infrared bandpass filter.
Camera is seeing 725nm to 850nm





Infrared BPR Filter.

Equipment: Sony DSC-F828 IR enabled and XNiteBPR infrared bandpass filter.
Camera is seeing 850nm to 950nm
