USB 8MP Mono UV

XNiteUSB8M-MNCUVL

USB 8MP Monochrome Debayered Camera No Coverglass Fused Silica Lens with UV Shortpass and IR Blocking Filters

You can jump to this item in our webstore by clicking here.





For those wanting a high quality, low cost simple solution for UV imaging, we are offering a completed UV camera and lens setup.  This is a much higher performance than our low cost USB 2MP version because this is a true monochrome camera, the sensor has no coverglass, microlenses or Color Filter Array (CFA), has a fused silica (similar to quartz) lens and stacked XNite330C (UV Shortpass) and XNiteBP1 (IR Blocking) filters.

Specifications:

  • USB 8 Megapixel Camera with the coverglass, microlenses and CFA removed exposing the bare photodiodes.  The coverglass, microlenses and CFA all block or reduce UV transmission.
  • USB camera shows up as a video device on most PC's, Mac's and Linux devices without any special drivers needed.  Any software that can see something like a webcams should be able to see this camera.
  • Llewellyn Optics fused silica 6mm F/5.6 lens can pass UV light to below 200nm.
  • Combined XNite330C UV shortpass filter and XNiteBP1 IR blocking filter are an excellent combination to restrict camera to 320nm-380nm.
  • Video Output includes 1080P and up to 3264 x 2448 Resolution
  • Focus can be adjusted by turning front lens to focus anywhere from less than 1 inch to infinity



XNiteUSB8M-MNCUVL used inside with our XNiteFlashF365-3W flashlight showing sunscreen being applied.



Camera Section Specifications

Model

XNiteUSB8M-MUV

Sensor

SONY IMX179

Lens Size

1/3.2inch

Pixel Size

1.4um

image area

6.18mm x 5.85mm

Max. Resolution

3264(H) X 2448(V)  8Megapixel

Compression format

MJPEG  / YUV2(YUYV)

Resolution & frame

3264X2448 @ 15fps  / 2592X1944@ 20fps

2048X1536 @ 20fps  / 1600X1200@ 20fps

1280X960 @ 20fps  / 1024X768@ 30fps

800X600 @ 30fps   / 640X480@ 30fps

S/N Ratio

34dB

Dynamic Range

72.5dB

Sensitivity

0.65V/lux-sec@550nm

Mini illumination

0.5lux

Shutter Type

Electronic rolling shutter / Frame exposure

Connecting Port type

USB2.0 High Speed

Free Drive Protocol

USB Video Class(UVC)

OTG protocol

USB2.0 OTG

AEC

Support

AEB

Support

AGC

Support

Button camera

Support

Adjustable parameters

Brightness,  Contrast, Saturation, Hue, Sharpness, Gamma,
Gain, White balance, Backlight Contrast, Exposure

Lens Parameter

Size:  1/3.2,  Iris:  F3.5,  Focus:  3.6mm ,  FOV:  75 Degree

LED board control interface

Support  2P-1.25mm socket

LED board power connector

Support  2P-2.0mm socket

Power supply

USB BUS POWER  4P-2.0mm socket

Operating Voltage

DC5V

Working current

150mA~240mA

Working temperature

-10~70℃

Storage temperature

-20~85℃

Board size

38X38mm(compatible 32X32mm)

Operating system request

WinXP/Vista/Win7/Win8

Linux with UVC(above linux-2.6.26)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or above with UVC
