| Sensor Type: |
CMOS |
| Sensor Manufacturer: |
|
| Effective Megapixels: |
16.2 |
| Sensor Format: |
35mm |
| Sensor size: |
860.4mm2 (36.00mm x 23.90mm) |
| Approximate Pixel Pitch: |
7.31 microns |
| Focal Length Multiplier: |
1.0x |
| Aspect Ratio: |
3:2 |
| Color Filter Type: |
RGBG |
| Anti Aliasing Filter: |
None |
| Self-Cleaning: |
Yes |
| Sensor shift image stabilization: |
No |
| On-Sensor Phase Detect: |
No |
| DxO Sensor Score: |
89 |
| DxO Color Depth Score (bits): |
24.4 |
| DxO Dynamic Range Score (evs): |
13.3 |
| DxO Maximum Effective ISO Score (iso): |
3,074 |
| Image Resolution: |
4928 x 3280 (16.2 MP, 3:2),
3696 x 2456 (9.1 MP, 3:2),
2464 x 1640 (4.0 MP, 3:2),
4096 x 2720 (11.1 MP, Other),
3072 x 2040 (6.3 MP, Other),
2048 x 1360 (2.8 MP, Other),
3200 x 2128 (6.8 MP, 3:2),
2400 x 1592 (3.8 MP, Other),
1600 x 1064 (1.7 MP, 3:2),
4096 x 3280 (13.4 MP, 5:4),
3072 x 2456 (7.5 MP, 5:4),
2048 x 1640 (3.4 MP, 5:4) |
| Image File Format: |
JPEG, NEF (RAW): 12 or 14 bit, lossless compressed, compressed, or uncompressed, small size availble (12-bit uncompressed only); TIFF (RGB) |
| Continuous-mode frames/second: |
10.6 |
| Can take movies: |
Yes |
| Movie Resolution: |
1920x1080 (60p/50p/30p/25p/24p)
1280x720 (60p/50p)
640x424 (30p/25p) |
| Movie File Format: |
MOV (Video: H.264/MPEG-4 AVC; Audio: Linear PCM) |
| Composite Video Out: |
No |
| NTSC/PAL Switchable Video: |
n/a |
| Video Usable as Viewfinder: |
n/a |
| HD Video Out: |
Yes |
| HD Video Connection: |
HDMI |
| Lens Mount: |
Nikon F |
| Lens: |
n/a |
| Focal Length (35mm equivalent): |
|
| Focal Length (actual): |
|
| Zoom Ratio: |
|
| Aperture Range: |
|
| Normal Focus Range: |
|
| Macro Focus Range: |
|
| Filter Thread: |
n/a |
| Thread Type: |
n/a |
| Optical Image Stabilization: |
No |
| Digital Zoom: |
|
| Digital Zoom Values: |
|
| Auto Focus: |
Yes |
| Auto Focus Type: |
Nikon Advanced Multi-CAM 3500FX autofocus sensor module with TTL phase detection, fine-tuning, and 51 focus points (including 15 cross-type sensors with f/8 supported by 11 sensors) |
| Auto Focus Assist Light? |
No |
| Manual Focus: |
Yes |
| Viewfinder: |
Optical / LCD |
| Viewfinder Type: |
SLR; eye-level pentaprism, 100% coverage, 0.7x magnification, 18mm eyepoint, -3 to +1 diopter |
| Focus Peaking: |
No |
| EVF Resolution: |
n/a |
| Viewfinder Magnification (35mm equivalent): |
0.70x |
| Viewfinder Magnification (nominal/claimed): |
0.70x |
| Eye-level Viewfinder: |
Yes |
| Rear Display: |
Yes |
| Rear Display Size (inches): |
3.2 |
| Rear Display Resolution: |
921,600 dots (307,200 px) |
| Touchscreen: |
No |
| Articulating Screen: |
No |
| Tilt Swivel Screen: |
No |
| Selfie Screen: |
No |
| Max Playback Zoom: |
46.0x |
| Top Deck Display: |
Yes |
| Maximum ISO (native): |
25600 |
| Minimum ISO (native): |
100 |
| ISO Settings: |
Auto, 100 - 25,600, plus down to 50 in Lo-1, up to 409,600 in Hi-4 |
| Auto ISO Mode: |
Yes |
| White Balance Settings: |
Auto (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shade, preset manual (up to 6 values can be stored, spot white balance measurement available during live view), color temperature (2500 K-10000 K) |
| Shutter Speed Range: |
30 - 1/8000 |
| Bulb Mode: |
Yes |
| Exposure Compensation: |
+/- 5.0EV in 0.3EV steps |
| Metering Modes: |
91K-pixel 3D Color Matrix Metering III, Center-weighted (75% given to 8, 12, 15 or 20mm circle), Spot (4mm) centered on selected focus area |
| Program Auto Exposure: |
Yes |
| Aperture Priority: |
Yes |
| Shutter Priority: |
Yes |
| Full Manual Exposure: |
Yes |
| Creative Exposure Modes: |
None |
| Self Timer: |
2/5/10/20s; 1-9 exposures at intervals of 0.5, 1, 2, or 3 seconds |
| Time Lapse (intervalometer): |
Yes |
| High Resolution Composite: |
No |
| Built-in Flash: |
No |
| Flash Modes: |
Front curtain sync, slow sync, rear-curtain sync, red-eye reduction, red-eye reduction with slow sync, slow rear-curtain sync, Auto FP High-Speed Sync supported |
| Flash Guide Number (ISO 100): |
n/a |
| Flash Range Description: |
n/a |
| Max Flash Sync: |
1/250 |
| Flash Exposure Compensation: |
-3 to +1 EV in 0.3EV steps |
| External Flash Connection: |
ISO 518 Hot Shoe; safety lock provided; PC Sync terminal |
| Built-In Wireless Flash Control: |
|
| Usable Memory Types: |
CF1 / XQD |
| UHS Support: |
|
| Other Memory: |
UDMA7 compliant |
| Dual Card Slots: |
Yes |
| RAW Capture Support: |
Yes |
| Uncompressed Format: |
NEF (RAW): 12 or 14 bit, lossless compressed, compressed, or uncompressed, small size availble (12-bit uncompressed only); TIFF (RGB) |
| Movie File Format: |
MOV (Video: H.264/MPEG-4 AVC; Audio: Linear PCM) |
| Included Memory: |
No memory included |
| Included Memory Type: |
|
| Built-In Wi-Fi: |
No |
| NFC: |
No |
| Bluetooth: |
No |
| Built-In GPS: |
No |
| Microphone Jack: |
Yes |
| Headphone Jack: |
Yes |
| External Connections: |
USB 2.0 High Speed,Ethernet |
| PictBridge Compliant: |
Yes |
| DPOF Compliant: |
Yes |
| Remote Control: |
Yes |
| Remote Control Type: |
Optional wired, wireless |
| Connections (extended): |
Type-C mini HDMI with uncompressed video support, DC Input, 10-pin Expansion Terminal, Audio input (stereo 3.5mm jack with power), Audio output (stereo 3.5mm jack), Peripheral connector for WT-5A/WT-4A |
| Cycle time for JPEG shooting in single shot mode (seconds per frame, max resolution): |
<0.3 |
| Cycle time for RAW shooting in single shot mode (seconds per frame): |
0.36 |
| Buffer size for RAW shooting in single shot mode (frames): |
Unlimited |
| Cycle time for RAW+JPEG shooting in single shot mode (seconds per shot): |
0.33 |
| Camera penalizes early shutter press? |
No |
| JPEG shooting speed in burst mode (fps, max resolution): |
10.6 |
| Buffer size for JPEG shooting in burst mode (frames, max resolution): |
Unlimited |
| RAW shooting speed in burst mode (fps): |
10.8 |
| Buffer size for RAW shooting in burst mode (frames): |
Unlimited |
| RAW+JPEG shooting speed in burst mode (fps): |
10.8 |
| Buffer Size for RAW+JPEG shooting in burst mode (frames): |
43 |
| Shutter lag (full AF, wide/mid): |
0.20 seconds |
| Shutter lag (full AF, tele): |
|
| Shutter lag (full AF, live view - DSLR): |
0.91 seconds |
| Shutter lag (prefocused, live view - DSLR): |
0.239 seconds |
| Shutter Lag (manual focus): |
0.044 seconds |
| Shutter lag (full AF, with flash): |
|
| Shutter Lag (prefocused): |
0.043 seconds |
| Shutter Lag (notes): |
OVF: Full AF lag, wide-area mode = 0.288s Live View: Full AF lag = 0.914s Prefocused = 0.239s |
| Startup Time: |
0.2 seconds |
| Play -> Record Time: |
0.2 seconds |
| Flash cycle time, full power: |
0.0 seconds |
| Battery Life, Stills (CIPA Rating Monitor/Live View): |
|
| Battery Life, Still (CIPA Rating OVF/EVF): |
3020 shots |
| Battery Life, Video: |
|
| Battery Form Factor: |
Proprietary EN-EL18A |
| Usable Battery Types: |
Lithium-ion rechargeable |
| Batteries Included: |
1 x Proprietary EN-EL18A Lithium-ion rechargeable |
| Battery Charger Included (dedicated charger or AC/USB adapter): |
Yes |
| Dedicated Battery Charger Included: |
Yes |
| Internal Charging Supported: |
No |
| Included Software: |
Nikon ViewNX 2 CD-ROM |
| OS Compatibility: |
Windows, Mac OS X |
| Notes & Features: |
New 16MP sensor with improved high ISO performance, EXPEED 4 processor, 11fps burst mode with AE/AF, improved AF, up to 1920x1080p60 video, new small RAW size option (2464 x 1640, 12-bit), improved battery life, built-in GbE LAN (1000Base-T), uncompressed 1080p60 HDMI output. |
