Note: For use in Sunlight, Hot Filament, Xenon Flash Tube or any light source that emits IR, you should use our XNiteBP1 filter on your lens for additional IR blocking. Because the camera sensor is very IR sensitive and not very UV sensitive, without the XNiteBP1 filter, you will end up with a lot of IR in the image.
| Sensor Type: |
CMOS |
| Sensor Manufacturer: |
Canon |
| Effective Megapixels: |
18.0 |
| Sensor Format: |
APS-C |
| Sensor size: |
332.27mm2 (22.30mm x 14.90mm) |
| Approximate Pixel Pitch: |
4.30 microns |
| Focal Length Multiplier: |
1.6x |
| Aspect Ratio: |
3:2 |
| Color Filter Type: |
RGBG |
| Anti Aliasing Filter: |
Fixed |
| Self-Cleaning: |
Yes |
| Sensor shift image stabilization: |
No |
| On-Sensor Phase Detect: |
No |
| DxO Sensor Score: |
66 |
| DxO Color Depth Score (bits): |
22.0 |
| DxO Dynamic Range Score (evs): |
11.7 |
| DxO Maximum Effective ISO Score (iso): |
854 |
| Image Resolution: |
5184 x 3456 (17.9 MP, 3:2),
3888 x 2592 (10.1 MP, 3:2),
3456 x 2304 (8.0 MP, 3:2),
2592 x 1728 (4.5 MP, 3:2) |
| Image File Format: |
JPEG, 14-bit RAW, MRAW, SRAW, RAW+JPEG |
| Continuous-mode frames/second: |
8.0 |
| Can take movies: |
Yes |
| Movie Resolution: |
1920x1080 (30p/25p/24p)
1280x720 (60p/50p)
640x480 (60p/50p) |
| Movie File Format: |
.MOV (H.264) |
| Composite Video Out: |
Yes |
| NTSC/PAL Switchable Video: |
Yes |
| Video Usable as Viewfinder: |
|
| HD Video Out: |
Yes |
| HD Video Connection: |
HDMI |
| Lens Mount: |
Canon EF/EF-S |
| Lens: |
Canon EF 28-135mm f/3.5-5.6 IS USM |
| Focal Length (35mm equivalent): |
45 - 216mm |
| Focal Length (actual): |
28 - 135mm |
| Zoom Ratio: |
3.80x |
| Aperture Range: |
f/3.5 - 22 (W), f/5.6 - 36 (T) |
| Normal Focus Range: |
50 cm to Infinity
19.7 in to Infinity |
| Macro Focus Range: |
|
| Filter Thread: |
72.0mm |
| Thread Type: |
n/a |
| Optical Image Stabilization: |
Yes |
| Digital Zoom: |
No |
| Digital Zoom Values: |
n/a |
| Auto Focus: |
Yes |
| Auto Focus Type: |
Phase-Detection: AF-dedicated CMOS Sensor, 19 cross-type AF points, f/2.8 rotated cross center point |
| Auto Focus Assist Light? |
Yes |
| Manual Focus: |
Yes |
| Viewfinder: |
Optical / LCD |
| Viewfinder Type: |
SLR type; fixed eye-level pentaprism, 100% coverage, 1.0x mag., 22mm eyepoint, -3 to +1 diopter |
| Focus Peaking: |
No |
| EVF Resolution: |
n/a |
| Viewfinder Magnification (35mm equivalent): |
0.63x |
| Viewfinder Magnification (nominal/claimed): |
1.00x |
| Eye-level Viewfinder: |
Yes |
| Rear Display: |
Yes |
| Rear Display Size (inches): |
3.0 |
| Rear Display Resolution: |
921,600 dots (307,200 px) |
| Touchscreen: |
No |
| Articulating Screen: |
No |
| Tilt Swivel Screen: |
No |
| Selfie Screen: |
No |
| Max Playback Zoom: |
10.0x |
| Top Deck Display: |
Yes |
| Maximum ISO (native): |
6400 |
| Minimum ISO (native): |
100 |
| ISO Settings: |
Auto, 100 - 6400 in 1/3 or 1EV steps, H=12800 |
| Auto ISO Mode: |
Yes |
| White Balance Settings: |
Auto, Daylight, Shade, Cloudy, Tungsten, White Fluorescent, Flash, Custom, Kelvin 2500K - 10,000K |
| Shutter Speed Range: |
30 - 1/8000 |
| Bulb Mode: |
Yes |
| Exposure Compensation: |
+/- 5.0EV in 0.3EV steps |
| Metering Modes: |
63-zone Evaluative, Center-weighted, Partial (9.4% at center), Spot (2.3% at center) |
| Program Auto Exposure: |
Yes |
| Aperture Priority: |
Yes |
| Shutter Priority: |
Yes |
| Full Manual Exposure: |
Yes |
| Creative Exposure Modes: |
Creative Auto, 3 Custom User Settings |
| Self Timer: |
10 or 2 seconds |
| Time Lapse (intervalometer): |
No |
| High Resolution Composite: |
No |
| Built-in Flash: |
Yes |
| Flash Modes: |
E-TTL II |
| Flash Guide Number (ISO 100): |
12.0 m / 39.4 ft. |
| Flash Range Description: |
Lens aperture dependent |
| Max Flash Sync: |
1/250 |
| Flash Exposure Compensation: |
+/- 3.0 EV in 0.3EV steps |
| External Flash Connection: |
Hot Shoe, PC Sync |
| Built-In Wireless Flash Control: |
Full TTL exposure |
| Usable Memory Types: |
CF1 / CF2 |
| UHS Support: |
|
| Other Memory: |
|
| Dual Card Slots: |
No |
| RAW Capture Support: |
Yes |
| Uncompressed Format: |
14-bit RAW, MRAW, SRAW, RAW+JPEG |
| Movie File Format: |
.MOV (H.264) |
| Included Memory: |
No memory included |
| Included Memory Type: |
|
| Built-In Wi-Fi: |
No |
| NFC: |
No |
| Bluetooth: |
No |
| Built-In GPS: |
No |
| Microphone Jack: |
Yes |
| Headphone Jack: |
No |
| External Connections: |
USB 2.0 High Speed |
| PictBridge Compliant: |
Yes |
| DPOF Compliant: |
Yes |
| Remote Control: |
Yes |
| Remote Control Type: |
Optional Wired or Wireless |
| Connections (extended): |
N3-type push-in terminal, HDMI mini out, external microphone jack, extension system terminal for WFT-E5A wireless file transmitter |
| Cycle time for JPEG shooting in single shot mode (seconds per frame, max resolution): |
<0.3 |
| Cycle time for RAW shooting in single shot mode (seconds per frame): |
<0.3 |
| Buffer size for RAW shooting in single shot mode (frames): |
22 |
| Cycle time for RAW+JPEG shooting in single shot mode (seconds per shot): |
0.32 |
| Camera penalizes early shutter press? |
No |
| JPEG shooting speed in burst mode (fps, max resolution): |
8.0 |
| Buffer size for JPEG shooting in burst mode (frames, max resolution): |
22 |
| RAW shooting speed in burst mode (fps): |
8.0 |
| Buffer size for RAW shooting in burst mode (frames): |
16 |
| RAW+JPEG shooting speed in burst mode (fps): |
7.9 |
| Buffer Size for RAW+JPEG shooting in burst mode (frames): |
6 |
| Shutter lag (full AF, wide/mid): |
0.13 seconds |
| Shutter lag (full AF, tele): |
|
| Shutter lag (full AF, live view - DSLR): |
1.10 seconds |
| Shutter lag (prefocused, live view - DSLR): |
0.202 seconds |
| Shutter Lag (manual focus): |
0.083 seconds |
| Shutter lag (full AF, with flash): |
0.24 seconds |
| Shutter Lag (prefocused): |
0.061 seconds |
| Shutter Lag (notes): |
Live View lag: Full Autofocus "Quick Mode" (Phase Detect) = 0.986s Full Autofocus "Live Mode" (Contrast Detect = 1.103s Prefocused = 0.202s |
| Startup Time: |
0.4 seconds |
| Play -> Record Time: |
0.1 seconds |
| Flash cycle time, full power: |
2.7 seconds |
| Battery Life, Stills (CIPA Rating Monitor/Live View): |
|
| Battery Life, Still (CIPA Rating OVF/EVF): |
800 shots |
| Battery Life, Video: |
|
| Battery Form Factor: |
Proprietary |
| Usable Battery Types: |
LP-E6 Lithium-ion rechargeble |
| Batteries Included: |
1 x Proprietary LP-E6 Lithium-ion rechargeble |
| Battery Charger Included (dedicated charger or AC/USB adapter): |
Yes |
| Dedicated Battery Charger Included: |
Yes |
| Internal Charging Supported: |
No |
| Included Software: |
Canon Solutions Disc version 21.0 (EOS Utility, ZoomBrowser EX/ImageBrowser, Digital Photo Professional.Picture Style Editor, Movie Edit Task, PhotoStitch, Memory Card utility, WFT Utility, Original Data Security Tool |
| OS Compatibility: |
Windows XP SP2/SP3 / Vista, Mac OS X 10.4-10.5 |
| Notes & Features: |
8 fps continuous mode, all new 19-point AF system, built-in flash can be wireless master, dual-axis electronic level. |
