| Sensor Type: |
CMOS |
| Sensor Manufacturer: |
Canon |
| Effective Megapixels: |
30.4 |
| Sensor Format: |
35mm |
| Sensor size: |
864mm2 (36.00mm x 24.00mm) |
| Approximate Pixel Pitch: |
5.36 microns |
| Focal Length Multiplier: |
1.0x |
| Aspect Ratio: |
3:2 |
| Color Filter Type: |
RGBG |
| Anti Aliasing Filter: |
Fixed |
| Self-Cleaning: |
Yes |
| Sensor shift image stabilization: |
No |
| On-Sensor Phase Detect: |
Yes |
| DxO Sensor Score: |
91 |
| DxO Color Depth Score (bits): |
24.8 |
| DxO Dynamic Range Score (evs): |
13.6 |
| DxO Maximum Effective ISO Score (iso): |
2,995 |
| Image Resolution: |
6720 x 4480 (30.1 MP, 3:2),
5040 x 3360 (16.9 MP, 3:2),
4464 x 2976 (13.3 MP, 3:2),
3360 x 2240 (7.5 MP, 3:2),
1920 x 1280 (2.5 MP, 3:2),
720 x 480 (0.3 MP, 3:2),
5952 x 4480 (26.7 MP, 4:3),
4480 x 3360 (15.1 MP, 4:3),
3968 x 2976 (11.8 MP, 4:3),
2976 x 2240 (6.7 MP, 4:3),
1696 x 1280 (2.2 MP, 4:3),
640 x 480 (0.3 MP, 4:3),
6720 x 3776 (25.4 MP, 16:9),
5040 x 2836 (14.3 MP, 16:9),
4464 x 2512 (11.2 MP, 16:9),
3360 x 1888 (6.3 MP, 16:9),
1920 x 1080 (2.1 MP, 16:9),
720 x 408 (0.3 MP, Other),
4480 x 4480 (20.1 MP, 1:1),
3360 x 3360 (11.3 MP, 1:1),
2976 x 2976 (8.9 MP, 1:1),
2240 x 2240 (5.0 MP, 1:1),
1280 x 1280 (1.6 MP, 1:1),
480 x 480 (0.2 MP, 1:1) |
| Image File Format: |
JPEG (EXIF v2.3), RAW, M-RAW (16.9MP), S-RAW (7.5MP), Dual-Pixel RAW; 14-bit CR2 |
| Continuous-mode frames/second: |
7.0 |
| Can take movies: |
Yes |
| Movie Resolution: |
4096x2160 (30p/25p/24p/23.98p)
1920x1080 (60p/50p/30p/25p/24p/23.98p)
1280x720 (120p/100p) |
| Movie File Format: |
MOV (4K video: Motion JPEG; Full HD and HD Movie: MPEG4 AVC/H.264; Audio: Linear PCM), MP4 (Movie: MPEG4 AVC/H.264; Audio: AAC) |
| Composite Video Out: |
No |
| NTSC/PAL Switchable Video: |
n/a |
| Video Usable as Viewfinder: |
n/a |
| HD Video Out: |
Yes |
| HD Video Connection: |
HDMI |
| Lens Mount: |
Canon EF |
| Lens: |
n/a |
| Focal Length (35mm equivalent): |
|
| Focal Length (actual): |
|
| Zoom Ratio: |
|
| Aperture Range: |
|
| Integrated ND Filter: |
No |
| Normal Focus Range: |
|
| Macro Focus Range: |
|
| Filter Thread: |
n/a |
| Thread Type: |
n/a |
| Optical Image Stabilization: |
No |
| Digital Zoom: |
|
| Digital Zoom Values: |
|
| Auto Focus: |
Yes |
| Auto Focus Type: |
Phase Detect: OVF: 61-point (up to 41 cross-type points); Up to 5 dual cross-type AF points at f/2.8 and f/5.6, up to 20 cross-type AF points at f/4 and f/5.6, up to 21 cross-type AF points at f/5.6 and f/8, up to 20 horizontal-line AF points at f/5.6, up to 61 horizontal-line AF points at f/8; Dual Pixel CMOS AF on sensor |
| Auto Focus Assist Light? |
No |
| Manual Focus: |
Yes |
| Viewfinder: |
Optical / LCD |
| Viewfinder Type: |
SLR type; fixed eye-level pentaprism, 100% coverage, 0.71x magnification, 21mm eyepoint, -3 to +1 diopter, fixed focusing screen, on demand grid |
| Focus Peaking: |
No |
| EVF Resolution: |
n/a |
| Viewfinder Magnification (35mm equivalent): |
0.71x |
| Viewfinder Magnification (nominal/claimed): |
0.71x |
| Eye-level Viewfinder: |
Yes |
| Rear Display: |
Yes |
| Rear Display Size (inches): |
3.2 |
| Rear Display Resolution: |
1,620,000 dots (540,000 px) |
| Touchscreen: |
Yes |
| Articulating Screen: |
No |
| Tilt Swivel Screen: |
No |
| Selfie Screen: |
No |
| Max Playback Zoom: |
10.0x |
| Top Deck Display: |
Yes |
| Maximum ISO (native): |
32000 |
| Minimum ISO (native): |
100 |
| ISO Settings: |
Auto, 100-32000 in 1/3 or 1 EV steps, expandable to 50 (L), 51200 (H1) and 102400 (H2) |
| Auto ISO Mode: |
Yes |
| White Balance Settings: |
Auto (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash, Custom, Color Temperature |
| Shutter Speed Range: |
1/8000 - 30 sec |
| Bulb Mode: |
Yes |
| Exposure Compensation: |
+/- 5.0EV in 0.3EV steps |
| Metering Modes: |
150K-pixel RGB+IR metering sensor, 252-zone Evaluative, Center-weighted, Partial (center 6.1% of frame), Spot (center 1.3% of frame) |
| Program Auto Exposure: |
Yes |
| Aperture Priority: |
Yes |
| Shutter Priority: |
Yes |
| Full Manual Exposure: |
Yes |
| Creative Exposure Modes: |
Custom shooting mode C1, C2, C3; Multiple-exposure; HDR |
| Self Timer: |
2, 10 seconds |
| Time Lapse (intervalometer): |
Yes |
| High Resolution Composite: |
No |
| Built-in Flash: |
No |
| Flash Modes: |
n/a |
| Flash Guide Number (ISO 100): |
n/a |
| Flash Range Description: |
n/a |
| Max Flash Sync: |
1/200 |
| Flash Exposure Compensation: |
+/- 3.0 EV in 0.3EV steps |
| External Flash Connection: |
Hot Shoe, PC Sync |
| Built-In Wireless Flash Control: |
No |
| Usable Memory Types: |
CF1 / SD / SDHC / SDXC |
| UHS Support: |
UHS-I |
| Other Memory: |
SD: UHS-I, CF: UDMA7 |
| Dual Card Slots: |
Yes |
| RAW Capture Support: |
Yes |
| Uncompressed Format: |
RAW, M-RAW (16.9MP), S-RAW (7.5MP), Dual-Pixel RAW; 14-bit CR2 |
| Movie File Format: |
MOV (4K video: Motion JPEG; Full HD and HD Movie: MPEG4 AVC/H.264; Audio: Linear PCM), MP4 (Movie: MPEG4 AVC/H.264; Audio: AAC) |
| Included Memory: |
No memory included |
| Included Memory Type: |
|
| Built-In Wi-Fi: |
Yes |
| NFC: |
Yes |
| Bluetooth: |
No |
| Built-In GPS: |
Yes |
| Microphone Jack: |
Yes |
| Headphone Jack: |
Yes |
| External Connections: |
USB 3.0 Super Speed,WiFi |
| PictBridge Compliant: |
Yes |
| DPOF Compliant: |
Yes |
| Remote Control: |
Yes |
| Remote Control Type: |
Optional Wired or Wireless |
| Connections (extended): |
Mini HDMI (Type C), Remote Jack, Stereo Mic Jack, Stereo Monitor Jack, PC-Sync Terminal |
| Cycle time for JPEG shooting in single shot mode (seconds per frame, max resolution): |
0.37 |
| Cycle time for RAW shooting in single shot mode (seconds per frame): |
|
| Buffer size for RAW shooting in single shot mode (frames): |
|
| Cycle time for RAW+JPEG shooting in single shot mode (seconds per shot): |
0.37 |
| Camera penalizes early shutter press? |
No |
| JPEG shooting speed in burst mode (fps, max resolution): |
7.0 |
| Buffer size for JPEG shooting in burst mode (frames, max resolution): |
Unlimited |
| RAW shooting speed in burst mode (fps): |
7.0 |
| Buffer size for RAW shooting in burst mode (frames): |
19 |
| RAW+JPEG shooting speed in burst mode (fps): |
7.0 |
| Buffer Size for RAW+JPEG shooting in burst mode (frames): |
12 |
| Shutter lag (full AF, wide/mid): |
0.17 seconds |
| Shutter lag (full AF, tele): |
|
| Shutter lag (full AF, live view - DSLR): |
|
| Shutter lag (prefocused, live view - DSLR): |
0.057 seconds |
| Shutter Lag (manual focus): |
0.077 seconds |
| Shutter lag (full AF, with flash): |
|
| Shutter Lag (prefocused): |
0.057 seconds |
| Shutter Lag (notes): |
|
| Startup Time: |
0.5 seconds |
| Play -> Record Time: |
0.2 seconds |
| Flash cycle time, full power: |
|
| Battery Life, Stills (CIPA Rating Monitor/Live View): |
300 shots |
| Battery Life, Still (CIPA Rating OVF/EVF): |
900 shots |
| Battery Life, Video: |
|
| Battery Form Factor: |
Proprietary LP-E6N |
| Usable Battery Types: |
Lithium-ion Rechargeable or BG-E20 battery grip |
| Batteries Included: |
1 x Proprietary LP-E6N Lithium-ion rechargeable |
| Battery Charger Included (dedicated charger or AC/USB adapter): |
Yes |
| Dedicated Battery Charger Included: |
Yes |
| Internal Charging Supported: |
No |
