USB-IND-5M-UV-Only: USB Industrial Monochrome 5.0 Megapixel Camera UV-Only

This camera includes Windows drivers and software for viewing and capturing pictures.

USB Industrial 5 Megapixel Camera with Monochrome Sensor and modified for UV-Only.

No Lens Included.

For outdoor use, you should also add our XNiteBP1 filter for additional IR blocking!




Pixels 5.0 MP Monochrome UV-Only

Sensor Size 5.7mm(H)x4.28mm(V)  1/2.5"
Pixel Size 2.2μm x 2.2μm
Resolution/
Frame Rate
2592 x 1944(full resolution):6FPS
2048 x 1536(ROI):9FPS
1920 x 1080(ROI):13.4FPS
1280 x 960(SUM):15FPS
1280 x 960(BIN):15FPS
640 x 480(SUM):23.7FPS
640 x 480(BIN):23.7FPS
Any Area(ROI)
Spectral
Response
380nm ~ 650nm (with infrared filter) / 300nm - 1100nm no ICF
Exposure
 Time
86μs ~ 3000ms
Sensitivity 1.4V/Lux-sec
Shutter Electronic Rolling Shutter
Image Data Format 8bit RAW format
Operating Mode Continuous output
Scanning Mode Progressive Scan
Exposure
Control
Manual / Auto / Area
White Balance Manual / One-Time / Auto / Area
Image Processing GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction / Sharpness/ saturation
Picture Format JPEG / BMP / PNG / RAW
Product ID User Defined
Software Interface  DirectShow / TWAIN
Operating System Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit)
Data Interface USB2.0 (B Type interface)
Lens Mount C/CS Mount
Dimension 45mm x 48mm x 36.4mm(Exclude lens mount)
PCB Size 39mm x 39mm  (2 pcs board)
Weight Approx. 112g (with case and fixed blocks)
Rotated Voltage USB5V power supply(No external power supply circuit)
Rated power < 1.5W
 Temperature operation :0~50℃ / storage:-20℃~60℃
Humidity Working :10%~90%RH(No condensation) / Storage:10%~60%RH
LED Pilot Light Lighting once plug/ flashing when working
