Leica D-Lux 16.8 (Type 109) Megapixel Camera Converted to Monochrome
You can learn more about the Leica monochrome cameras by clicking here.
| Body type |
| Body type |
Large sensor compact |
| Sensor |
| Max resolution |
4736 x 3552 |
| Other resolutions |
4928 x 3288 (3:2), 5152 x 2904 (16:9), 3552 x 3552 (1:1) |
| Image ratio w:h |
1:1, 4:3, 3:2, 16:9 |
| Effective pixels |
17 megapixels |
| Sensor photo detectors |
22 megapixels |
| Sensor size |
Four Thirds (17.3 x 13 mm) |
| Sensor type |
CMOS |
| Image |
| ISO |
Auto, 200-25600 (expands down to 100) |
| Boosted ISO (minimum) |
100 |
| White balance presets |
5 |
| Custom white balance |
Yes (4 slots) |
| Image stabilization |
Optical |
| Uncompressed format |
RAW |
| JPEG quality levels |
Fine, standard |
| Optics & Focus |
| Focal length (equiv.) |
24–75 mm |
| Optical zoom |
3.1× |
| Maximum aperture |
F1.7–2.8 |
| Autofocus |
- Contrast Detect (sensor)
- Multi-area
- Center
- Selective single-point
- Tracking
- Single
- Continuous
- Touch
- Face Detection
- Live View
|
| Digital zoom |
Yes (4.3x - 6.2x) |
| Manual focus |
Yes |
| Normal focus range |
50 cm (19.69″) |
| Macro focus range |
3 cm (1.18″) |
| Number of focus points |
49 |
| Screen / viewfinder |
| Articulated LCD |
Fixed |
| Screen size |
3″ |
| Screen dots |
1,240,000 |
| Touch screen |
Yes |
| Screen type |
TFT LCD |
| Live view |
Yes |
| Viewfinder type |
Electronic |
| Viewfinder coverage |
100% |
| Viewfinder magnification |
0.7× |
| Viewfinder resolution |
2,760,000 |
| Photography features |
| Minimum shutter speed |
1800 sec |
| Maximum shutter speed |
1/4000 sec |
| Maximum shutter speed (electronic) |
1/16000 sec |
| Aperture priority |
Yes |
| Shutter priority |
Yes |
| Manual exposure mode |
Yes |
| Built-in flash |
No |
| External flash |
Yes |
| Continuous drive |
11.0 fps |
| Self-timer |
Yes |
| Metering modes |
- Multi
- Center-weighted
- Spot
|
| Exposure compensation |
±5 (at 1/3 EV steps) |
| AE Bracketing |
±3 (3, 5, 7 frames at 1/3 EV, 2/3 EV, 1 EV steps) |
| WB Bracketing |
Yes |
| Videography features |
| Format |
MPEG-4, AVCHD, H.264 |
| Modes |
- 3840 x 2160 @ 30p / 100 Mbps, MP4, H.264, AAC
- 3840 x 2160 @ 24p / 100 Mbps, MP4, H.264, AAC
- 1920 x 1080 @ 60p / 28 Mbps, MP4, H.264, AAC
- 1920 x 1080 @ 60p / 28 Mbps, AVCHD, MTS, H.264, Dolby Digital
- 1920 x 1080 @ 60i / 17 Mbps, AVCHD, MTS, H.264, Dolby Digital
- 1920 x 1080 @ 30p / 20 Mbps, MP4, H.264, AAC
- 1920 x 1080 @ 30p / 24 Mbps, AVCHD, MTS, H.264, Dolby Digital
- 1280 x 720 @ 30p / 10 Mbps, MOV, H.264, Linear PCM
- 1920 x 1080 @ 24p / 24 Mbps, AVCHD, MTS, H.264, Dolby Digital
|
| Microphone |
Stereo |
| Speaker |
Mono |
| Storage |
| Storage types |
SD/SDHC/SDXC (UHS-I supported) |
| Connectivity |
| USB |
USB 2.0 (480 Mbit/sec) |
| USB charging |
Yes |
| HDMI |
Yes (micro HDMI) |
| Microphone port |
No |
| Headphone port |
No |
| Wireless |
Built-In |
| Wireless notes |
802.11b/g/n + Bluetooth 4.2 LE |
| Remote control |
Yes (via smartphone) |
| Physical |
| Environmentally sealed |
No |
| Battery |
Battery Pack |
| Battery description |
DP-DC15 lithium-ion battery & USB charger |
| Battery Life (CIPA) |
340 |
| Weight (inc. batteries) |
403 g (0.89 lb / 14.22 oz) |
| Dimensions |
118 x 66 x 64 mm (4.65 x 2.6 x 2.52″) |
| Other features |
| Orientation sensor |
Yes |
| GPS |
None |
